Evaporator of flake ice machine

The composition of the evaporator

The evaporator of flake ice maker is driven by the ice knife, sprinkler tray, main shaft, and water receiving tray, which rotates slowly counterclockwise under the drive of the reducer. Water enters the water diversion tray from the water inlet of the evaporator of the ice maker, and sprinkles the water evenly on the icy surface through the sprinkler pipe to form a water film; the water film exchanges heat with the refrigerant in the refrigerant flow channel, and the temperature drops rapidly , Forming a thin layer of ice on the icy surface, under the squeeze of the ice skates, it breaks into flakes of ice and falls into the ice storage from the ice falling port. Part of the uniced water flows back into the cold water tank from the water return port through the water tray, and is recycled through the cold water circulating pump.

Flake ice machines have been widely used in aquatic products, food, supermarkets, dairy, medicine, chemistry, vegetable preservation and transportation, marine fishing and other industries. With the development of society and the continuous improvement of people’s production levels, the industries that use ice have become more and more extensive. The requirements for ice quality are getting higher and higher. The requirements for "high performance", "low failure rate", and "hygiene" of ice machines are becoming more and more urgent.

Application of flake ice making machine

1. Application in the processing of aquatic products: flake ice can reduce the temperature of the processing medium, washing water and aquatic products, prevent the growth of bacteria, and keep the aquatic products fresh during the processing.

2. Application in the processing of meat products: Mixing flake ice that meets hygienic standards into meat and stirring. In order to achieve the purpose of cooling and keeping fresh.

3. Food processing applications: For example, when mixing or adding cream twice in bread production, use flake ice to quickly cool down to prevent fermentation.

4. Application in supermarkets and aquatic product markets: for the preservation, display and packaging of aquatic products

5. Application of vegetable processing process: The use of flake ice during the harvesting and processing of agricultural products and vegetables reduces the metabolism of agricultural products and the growth rate of bacteria. Extend the shelf life of agricultural products and vegetables.

6. Application of long-distance transportation: Ocean fishing, vegetable transportation and other products that require cooling and freshness are increasingly using flake ice to cool and keep fresh during long-distance transportation.

7. It is also widely used in laboratories, medicine, chemical industry, artificial ski resorts and other industries.

⒏Application in concrete engineering: When the concrete is poured in a large area in the hot season, the pouring temperature of the concrete must be controlled effectively and reasonably. Flake ice + cold water mixing is the most effective way.

Flake ice has obvious advantages compared with traditional ice cubes (large block ice) and snowflake ice. It is dry, not easy to agglomerate, has good fluidity, and has good hygiene. It has a large contact area with fresh-keeping products and is not easy to damage fresh-keeping products. It is the preferred product to replace other types of ice in many industries. And has:

1. High ice making efficiency and low cooling loss:

The automatic flake ice machine adopts the latest vertical internal spiral knife ice-cutting evaporator. When making ice, the water divider inside the ice bucket evenly distributes water to the inner wall of the ice bucket and freezes quickly. The ice knife cuts the ice and falls, so that the surface of the evaporator is allowed to be used, and the efficiency of the ice maker is improved.

2. The borneol is of good quality and does not stick when dry:

The vertical evaporator of the automatic flake ice machine produces irregular scaly ice with a thickness of 1-2 mm and good fluidity. 3. Simple structure, small area

The automatic flake ice machine has various series such as fresh water type, sea water type, self-contained cold source, user-equipped cold source, and ice storage. The daily ice output varies from 500Kg/24h to 60000Kg/24h and other specifications. The user can choose the suitable model according to the use occasion and the quality of the water used. Compared with the traditional ice machine, it has a small footprint and low operating cost (no need to remove the ice and fetch the ice).

Features of ice flake maker machine

1. Directly low temperature and low ice temperature, which can reach below -8°.

2. The ice is dry and clean, has a beautiful shape, is not easy to form a block, has good fluidity, and is hygienic and convenient.

3. The flake structure, so the contact area with the refrigerated products is large, and the cooling effect is wonderful.

4. Flake ice has no sharp edges and corners, which will not damage the surface of refrigerated products, and is very conducive to storage and transportation.

5. The thickness of ice can reach 1mm-2mm, and it can be used at any time without ice crusher.

6. The surface area can reach more than 1500 square meters per ton.
